RUG-Z
Retail price
0.0
元
Market price
0.0
元
Number of views:
0
Product serial number
Category
Calibration resistor series
Quantity
-
+
Stock:
0
Description
Parameters
Details
characteristic
-Constant power up to 500W(R-Z)
- DC current up to 700A (R-Z)
- Highest current and precision
- High pulse power up to 200J
- Very low TCR, calibration and reference resistance
Advantages/Features
- Four terminal connection
- Can withstand 500V AC voltage
-Optimized cooling
- Can be calibrated by DAKKS
technical parameter
Resistance range: 0.03 mOhm-100 Ohm
Accuracy: 0.01%, 0.1%, 0.5%, 1%
Power: Max? 500W
Temperature coefficient: min. 1ppm/k (+20°C to +60°C)
Thermal resistance: ﹤0.02K/W
Applicable temperature: -55℃ to +85℃
Insulation voltage: 500V AC
Inductance value: ﹤3nH
Stability (rated load) deviation: <0.1% after 2000h (TK＝+75℃)
TK = Terminal temperature: (R-Z)
Keyword:
RUG-Z
